The REEVES® Vari-Speed motor pulleys and accessories provide economical, trouble-free adjustable speed drives for the fractional through 15 HP range. Easy application and rugged design have made these drives a favorite machinery design option for many years. Produced in our Columbus, IN facility, most are available to ship within 48 hours.
Features:
- Suitable for motor frames 56 to 256T
- Economical adjustable speed drives with rugged designs
- Easy-to-install and maintain
- Extra-Value (XV) features to reduce maintenance time and costs
- Produced in our Columbus, IN facility
- Available in 48 hours
Junior Pulley – Only one moving part makes REEVES® Jr. Pulleys extra reliable and easy to maintain.
- ¼ to 1-½ HP
- 2.75:1 Speed Range
- Easily Lubricated: Contaminants flushed from sliding surfaces
- Patented closed groove lube system with grease reserve
- Uses standard A or B section belts
- Driven sheave options include FHP or Dual-Duty Taper-Lock sheaves
- Fast, simple set screw mounting
Senior Pulley – Easy to apply, easy to install and easy to maintain
- ¼ to 15 HP
- 3:1 Speed Range
- Uses industry standard wide range belts
- Taper-lock flat face pulley is driven sheave
- Self-contained spring cartridge for safety
- XV Features on ¼ HP – 10HP models
- Sliding disc rides on tough engineered Elastomeric Bushing: Eliminates the need for lubrication; Will not corrode or stick; quick, easy replacement
- Clamp Collar Mounting (Collet-style hub secured by compression clamp) for superior shaft grip, concentric mount keeps wear and vibration to a minimum and no fretting corrosion means easy removal for maintenance
- Ductile Iron Discs are machined all over for smooth running, also stronger and more wear resistant than cast iron or aluminum
REEVES® Vari-Speed Pulley Catalog
Product Installation and Instruction Manuals
- REEVES® Pulley and Motor Base Catalog
- REEVES® Senior Pulleys 5675, 9205, 1110, 912-15 and 90-series Motor Bases (G-3032)
- REEVES® Compound Pulleys CP5675, CP7202, CP1110 (G-3037)
- REEVES® Junior Pulleys 830, 850, 870, 875 (G-3011)
- REEVES® Pulley Comparison – Old Styles to Current
